AprilAire S86NMUPR Multi-Stage Programmable IAQ Thermostat
AprilAire S86NMUPR Multi-Stage Programmable IAQ Thermostat
Available to order — ships from incoming stock
Typically ships in 1–3 Business Days (Western Canada) · 3–6 Business Days (Eastern Canada)
SKU:S86NMUPR
Multi-stage temperature control plus programmable AprilAire Indoor Air Quality functions - without Wi-Fi.
The AprilAire S86NMUPR is a non-communicating multi-stage universal thermostat with programmable IAQ control. It supports 2H/2C conventional or 4H/2C heat-pump equipment while adding compatible humidity, ventilation and Event-Based™ Air Cleaning functions.
The capacitive-touch color interface and real-language menus are designed for easier setup, scheduling and homeowner operation.
Key Features
- 2H/2C conventional or 4H/2C heat-pump capability.
- Programmable IAQ control for compatible AprilAire equipment.
- Event-Based™ Air Cleaning with compatible whole-home air purifier.
- Humidity and ventilation control.
- Color graphical display and capacitive-touch interface.
- Real-language setup and flexible schedule programming.
- 8052 outdoor temperature sensor included by AprilAire.
- Non-Wi-Fi local control.
Application & Compatibility
Use the S86NMUPR when the project needs S86 multi-stage HVAC capability and hardwired IAQ control, but remote app control is not required. For Wi-Fi and Z10 wireless sensor compatibility, select the S86WMUPR.
Key Specifications
| Model | S86NMUPR |
|---|---|
| Control Type | Non-communicating programmable IAQ thermostat |
| Conventional Stages | 2H/2C |
| Heat Pump Stages | 4H/2C |
| IAQ Control | Humidity, ventilation, Event-Based Air Cleaning |
| Connectivity | No Wi-Fi |
| Included Sensor | 8052 outdoor temperature sensor |
| Approx. Size | 4.38 x 4.38 x 0.8 in |
Related AprilAire Products
- AprilAire 8022 3-Wire to 4-Wire Thermostat Adapter
- AprilAire 8051 Flush-Mount Temperature Sensor
- AprilAire 8052 Outdoor / Duct Temperature Sensor
- AprilAire 8053 Surface-Mount Temperature Sensor
- AprilAire 8086 Wall Cover for S86 Series Thermostats
Frequently Asked Questions
Does the S86NMUPR have Wi-Fi?
No. It provides local programmable control. The S86WMUPR is the Wi-Fi model in the S86 family.
Does it include the 8052 sensor?
Yes. AprilAire lists an 8052 outdoor temperature sensor in the S86NMUPR package.
Can it use Z10 wireless sensors?
AprilAire specifies Z10IDT and Z10ODT wireless sensor compatibility for the S86WMUPR, not the S86NMUPR.
