Simply45 24-Port Cat6A STP Loaded Patch Panel 1RU — 110 Punchdown | S45-2724S
Simply45 24-Port Cat6A STP Loaded Patch Panel 1RU — 110 Punchdown | S45-2724S
Available to order — ships from incoming stock
Typically ships in 2–4 Business Days (Western Canada) · 4–7 Business Days (Eastern Canada)
SKU:S45-2724S
Simply45 24-Port Cat6A STP Loaded Patch Panel 1RU — 110 Punchdown — S45-2724S
The S45-2724S is a commercial-grade 24-port shielded (STP) Cat6/6A loaded patch panel for 1U rack space. Pre-loaded with 24 shielded keystone jacks and a rear cable management bracket — ready to terminate on arrival. Designed for Canadian commercial, healthcare, data centre, and government network closets where shielded infrastructure is specified.
Built for Shielded Installations
The S45-2724S maintains shield continuity from the cable through the keystone to the patch panel chassis — critical in full-system STP deployments. The rear 110-style punchdown termination is the standard method for Canadian commercial structured cabling, compatible with all standard 110 punchdown tools (impact or non-impact).
The included rear cable management bracket organizes horizontal cable runs behind the panel, reduces stress on terminations, and keeps the IDF closet clean — a requirement on most institutional project specifications.
Technical Specifications
| Part Number | S45-2724S |
| Brand | Simply45 (SimplyBRANDS) |
| Ports | 24 × RJ45 (110 Punchdown, Shielded) |
| Cable Compatibility | Cat6 / Cat6A / Cat7 / Cat7A STP |
| Performance Standard | 10GBaseT, ANSI/TIA 568.2-D |
| Form Factor | 1U (1RU), 19-inch rack mount |
| Termination Style | 110 Punchdown (rear) |
| Cable Management | Rear bracket included |
| Shielding | Full chassis ground — continuous STP/SFTP shield |
| Certification | cUL Listed (E520614) |
| Country of Origin | Taiwan |
| UPC | 817777019926 |
| Dimensions (pkg) | 13" × 8" × 6" — 4 lbs |
| Warranty | Limited Lifetime |
| HTS Code (Canada) | 8537.10.9150 |
Frequently Asked Questions
Does the S45-2724S ship with keystones pre-installed?
Yes — "loaded" means the 24 STP keystone jacks are factory-installed in the panel chassis. You terminate cable at the rear 110 punchdown positions directly.
Is a punchdown tool required for installation?
Yes. A standard 110 punchdown tool (impact or non-impact) is required to seat conductors at the rear termination points.
How many panels fit in a standard 12U wall-mount enclosure?
A 12U enclosure holds up to 12 × 1U panels — 288 ports of Cat6A STP with S45-2724S panels.
