Simply45 PROSeries Cat6/6A UTP Pass-Through RJ45 Plugs with Cap45™ — 500pc Jar | S45-1705P
Simply45 PROSeries Cat6/6A UTP Pass-Through RJ45 Plugs with Cap45™ — 500pc Jar | S45-1705P
Available to order — ships from incoming stock
Typically ships in 2–4 Business Days (Western Canada) · 4–7 Business Days (Eastern Canada)
SKU:S45-1705P
Simply45 PROSeries Cat6/6A UTP Pass-Through RJ45 Plugs with Cap45™ — 500pc — S45-1705P
The S45-1705P is Simply45's large-format commercial project jar: 500 PROSeries pass-through RJ45 modular plugs for Cat6 and Cat6A UTP cable. Red-tinted for instant field identification. Built for structured cabling contractors running high-volume commercial installations across Canada.
Why Canadian Contractors Specify PROSeries
Simply45 PROSeries plugs are cUL Listed — the certification required on commercial structured cabling projects governed by Canadian electrical codes and procurement standards. The 3-prong, 50µ 24ct gold-plated pin design delivers lower contact resistance and better PoE/PoH performance than 2-prong alternatives on the market.
Cap45™ (Patent 10,811,831 B1) snaps onto the front of the plug after termination, covering exposed wire ends. This eliminates electrical risk on PoE/PoH circuits and satisfies safety requirements on commercial and institutional projects.
Technical Specifications
| Part Number | S45-1705P |
| Brand | Simply45 (SimplyBRANDS) |
| Plug Type | PROSeries Pass-Through (Single-Piece, No Load Bar) |
| Cable Compatibility | Cat6 / Cat6A UTP, 23–24 AWG solid; 28–26 AWG stranded |
| Conductor Range OD | 1.05–1.20 mm (0.041?–0.047?) |
| Max Cable OD | 7.4 mm (0.291?) |
| Pin Design | 3-Prong, 50µ 24ct Gold-Plated |
| Color | Red Tint |
| Quantity | 500 pc / jar |
| UOM | Pack (500pc jar) |
| Standards | ANSI/TIA 568.2-D, ISO/IEC 11801 Class E/Ea, 10GBaseT |
| Certification | cUL Listed (E520614), UL94 V0, FCC |
| Compatible Crimper | S45-C100, S45-C101, S45-C360, S45-C370 |
| Country of Origin | Taiwan |
| UPC | 810093721962 |
| Weight | 1.25 lbs |
| Warranty | Limited Lifetime |
| HTS Code (Canada) | 8536.69.4040 |
Frequently Asked Questions
What is the difference between S45-1605P and S45-1705P?
The S45-1605P is optimized for Cat6 UTP (23 AWG, max 7.0mm OD). The S45-1705P accommodates larger-diameter Cat6/6A cables with conductor OD up to 1.20mm and max jacket OD of 7.4mm — the right choice for thicker-jacket commercial cable runs.
Are these plugs rated for PoE/PoH?
Yes. The 3-prong gold-plated pin design reduces contact resistance for reliable performance on PoE (802.3af/at/bt) and PoH applications.
Is Cap45 included?
Yes. Every S45-1705P jar ships with Cap45 isolation caps included.
