Monitor Audio Radius On-Wall 4G Speaker | RAD4GOW

Monitor Audio Radius On-Wall 4G Speaker | RAD4GOW

In Stock (Ready to Ship)

Typically ships in 4–8 Business Days (Western Canada) · 2–5 Business Days (Eastern Canada)

SKU:RAD4GOWB

MPN: RAD4GOWB

Shipping terms (Free over $300) calculated at checkout.
Color

Dealer planning note: Sign in for Simply Controlled dealer pricing. Confirm project quantity, finish availability and lead time before releasing the BOM.

Monitor Audio Radius On-Wall 4G is a slim passive, 2-way loudspeaker designed specifically for wall-mounted TV, film, stereo and multichannel installations. It is sold as a single speaker, allowing the required quantity to be selected for left, centre, right, surround or other wall-mounted channel layouts.

Two 4.5-inch RST III C-CAM bass-mid drivers work with a 25 mm C-CAM Gold Dome tweeter in a ported enclosure only 78 mm deep. Monitor Audio publishes a 69 Hz–35 kHz in-room response (-6 dB), 90 dB installed sensitivity, 114 dB maximum peak SPL and 100 W continuous power handling.

Radius On-Wall 4G at a glance

  • Sold as: Single speaker — order the quantity required for the system layout.
  • Speaker type: Passive, wired, 2-way on-wall loudspeaker.
  • Primary application: Slim wall-mounted audio around a TV / screen or within a multichannel system.
  • Orientation: Vertical or horizontal.
  • Driver system: 2 × 4.5 in RST III C-CAM bass-mid drivers + 1 × 25 mm C-CAM Gold Dome tweeter.
  • Bass alignment: Ported; 62 Hz tuning.
  • Nominal / minimum impedance: 8 ohms / 4.4 ohms at 700 Hz.
  • Installation hardware: Wall bracket and fixing template supplied.
  • Finishes: High Gloss Black and Satin White.
  • Warranty: 5 years.

Designed around the screen

Monitor Audio designs Radius On-Wall 4G as a low-profile solution that can integrate around a television or projection screen without the floor space and cabinet projection of a conventional stand-mount or floorstanding loudspeaker.

The speaker supports horizontal or vertical placement. A removable Monitor Audio roundel logo allows the visual orientation to remain clean whichever way the cabinet is installed. This makes a single product format usable across different wall-mounted channel positions.

Single-speaker purchasing

Radius On-Wall 4G is sold individually, not as a pair. That is important for system planning: order two for a stereo pair, one for a single channel, or the exact number required for a larger wall-mounted multichannel layout.

The single-unit sell model also avoids forcing an unnecessary pair when the product is being used as one centre or surround channel.

Wall bracket and fixing template supplied

Monitor Audio supplies a wall bracket and fixing template with Radius On-Wall 4G. The template supports consistent bracket positioning before the speaker is hung, while the cabinet itself remains only 78 mm deep with all accessories fitted.

Wall construction and fixing requirements vary. Confirm the substrate, fastener type, cable route and required load capacity for the actual installation rather than assuming one universal wall fixing method.

Driver and ported enclosure design

Radius On-Wall 4G uses two 4.5-inch RST III C-CAM bass-mid drivers around a 25 mm C-CAM Gold Dome tweeter. Monitor Audio publishes a crossover frequency of 2.3 kHz.

The enclosure is ported with a published tuning frequency of 62 Hz. The current manufacturer page also references HiVe II port technology. This is an exact-model specification and should not be confused with the sealed Radius 1 4G architecture.

Amplifier matching

Radius On-Wall 4G is rated at 8 ohms nominal and reaches a published minimum impedance of 4.4 ohms at 700 Hz. Continuous power handling is 100 W (CTA 426-B).

Monitor Audio recommends 50–100 W RMS into 8 ohms or 100–200 W RMS into 4 ohms with a music signal. The speaker remains an 8-ohm nominal design; the 4-ohm figure describes the amplifier's rated-output condition used for the recommendation.

Audio specifications

System format 2-way, passive on-wall loudspeaker
Frequency response 69 Hz–35 kHz, in-room (-6 dB)
Sensitivity 90 dB (2.83 Vrms @ 1 m, installed)
Free-field sensitivity Not published for this current model
Maximum peak SPL 114 dB (AES75, Z-weighted)
Nominal impedance 8 ohms
Minimum impedance 4.4 ohms @ 700 Hz
Continuous power handling 100 W (CTA 426-B)
Recommended amplifier power 50–100 W into 8 ohms; 100–200 W into 4 ohms (RMS, music signal)
Crossover LF/HF: 2.3 kHz
Bass alignment Ported
Port tuning 62 Hz

Drivers and installation design

Bass-mid drivers 2 × 4.5 in RST III C-CAM
Tweeter 1 × 25 mm C-CAM Gold Dome
Mounting orientation Vertical or horizontal
Wall bracket Included
Fixing template Included
Logo Removable MA roundel to support either orientation
Connection type Wired / external amplification required

Dimensions and weight

Dimensions (H × W × D) 750 × 154 × 78 mm, all accessories fitted
Imperial dimensions 29 1/2 × 6 1/16 × 3 1/16 in
Weight 6.4 kg / 14 lb 2 oz each
Verified shipping / packed weight Not currently available from the approved source stack

System planning

The 69 Hz published low-frequency limit describes the speaker itself, not a complete home-cinema bass-management strategy. Monitor Audio specifically notes that a subwoofer can be added when deeper full-range system output is required. The final AV crossover and bass-management settings should be determined during receiver / processor setup for the actual room and subwoofer configuration.

Finish and SKU identification

Finish SKU / MPN
High Gloss Black RAD4GOWB
Satin White RAD4GOWSW

GTIN note: commercial GTIN candidates exist for both Radius On-Wall 4G finishes, but they remain verification-only in the approved truth source. They are intentionally not published here until matched to a stronger identifier source.

Important purchase detail: Radius On-Wall 4G is sold as a single speaker. A stereo pair requires two units; multichannel systems should be ordered according to the number of channels required.

Warranty

Monitor Audio's current product page supports a 5-year warranty for Radius On-Wall 4G.
