Lutron QSH-CBL-M-500 Sivoia QS Medium-Distance Control Cable (500ft)

The Lutron QSH-CBL-M-500 is a high-quality, composite 5-conductor cable specifically designed for wiring Lutron Sivoia QS shades, drapery systems, and GRAFIK Eye QS controllers. As the "Medium" (M) distance variant, this cable features 16 AWG power conductors, which provide lower resistance than standard data cables to ensure your motorized window treatments receive consistent, reliable power.

This cable is a "one-pull" solution, combining power, common, and a shielded data pair for the QS Link (Mux Data) into a single 0.26-inch diameter jacket. This 500-foot spool is Non-Plenum (CL3) rated, making it ideal for residential and commercial projects where cable is run through walls or ceilings that do not serve as environmental air plenums.

Key Features

• Standard Industry Choice: 16 AWG power conductors are suitable for the majority of standard-length Sivoia QS wiring runs.
• Data Integrity: Includes a shielded 22 AWG twisted pair to ensure the QS Link communication signal remains free from interference.
• Simplified Installation: A single jacket houses all 5 conductors plus a drain wire, reducing labor time and clutter during wire pulls.
• Slim Profile: With an outer diameter of only 0.26 inches, this cable is easier to fish through tight spaces and wall cavities than the "Long" (L) version.
• Safety & Compliance: UL and CSA listed; RoHS compliant; CL3 rated for in-wall use.

Technical Specifications

Applications

• Sivoia QS Motorized Shades, Blinds, and Drapery
• QS Link Wired Communication for GRAFIK Eye QS
• Wired seeTouch QS Keypads
• Centralized Power Supply to Load Communication
