Lotus Surface Mount 3D Bendable LED Neonflex 24V DC 2.4W/ft 10mm CRI 90+ IP67 | ES-1010HB-C-10W-IP67

Overview

The Lotus LED Recessed Mount Side Bendable LED Neonflex is an architectural-spec, waterproof linear lighting solution designed for seamless integration into surfaces. This 24V constant voltage fixture provides a smooth, hotspot-free glow without the need for a diffused cover or aluminum channel, making it ideal for high-end recessed undercabinet and linear accent applications. Engineered with a reinforced design, it ensures stable performance during side-bending installations in both indoor and outdoor wet locations.

Key Features

• Seamless Linear Output: Delivers uniform illumination with no hotspots, eliminating the requirement for additional bulky aluminum channels or covers.
• Architectural-Spec Construction: Features a 4 oz copper PCB and real gold wires to ensure superior light maintenance and long-term durability.
• Side-Bendable Flexibility: Specifically designed with a reinforced structure to maintain stable performance and light quality when bending horizontally.
• Wet Location Rated: IP67 waterproof construction allows for reliable use in demanding environments, supported by a 3-year outdoor warranty.
• Vibrant Color Accuracy: Boasts a CRI of 90+ for high-quality color rendering in professional lighting designs.

Technical Specifications

• Input Voltage: 24V DC
• Power Consumption: 3 W/ft (10 W/m)
• Light Output: 180 lm/ft to 204 lm/ft depending on CCT
• Color Temperature: 2700K, 3000K, 4000K, 5000K
• CRI: 90+
• Beam Angle: 110°
• Dimmable: Yes
• IP Rating: IP67 (Wet Location)
• Dimensions: 3/8" x 3/8" (10 mm x 10 mm)
• Cuttable Increment: 4" (100 mm)
• Minimum Bending Diameter: 4" (100 mm) Horizontal
• Maximum Connection Length: 16 ft
• Operating Temperature: -4°F (-20°C) to +113°F (+45°C)
• Projected Life: 70% light output at 50,000 hours
• Certification: cULus
• Warranty: 5 Year Indoor / 3 Year Outdoor (when used with Lotus LED Lights driver)
