Monitor Audio CF230 Flush-Fit Mini In-Ceiling Speaker | CF230
Monitor Audio CF230 Flush-Fit Mini In-Ceiling Speaker | CF230
In Stock (Ready to Ship)
Typically ships in 4–8 Business Days (Western Canada) · 2–5 Business Days (Eastern Canada)
SKU:CF230
Dealer planning note: Sign in for Simply Controlled dealer pricing. Confirm project quantity, finish availability and lead time before releasing the BOM.
Monitor Audio CF230 is a compact architectural loudspeaker designed for highly discreet custom installations. Its coincident driver assembly combines a 3-inch C-CAM bass-mid driver and 19 mm C-CAM Gold Dome tweeter in a small opening that can be installed as a flush-fit pre-construction system or as a trimless retrofit.
CF230 at a glance
- Frequency response: 100 Hz–25 kHz (-6 dB).
- Sensitivity: 82.5 dB (1 W @ 1 m).
- Nominal impedance: 8 ohms.
- Power handling: 30 W RMS full range; up to 100 W music program with a 120 Hz high-pass filter.
- Driver: 3 in C-CAM bass-mid with coincident 19 mm C-CAM Gold Dome tweeter.
- Sold as: Single unit.
- Warranty: Lifetime.
Installation planning
The grille diameter is 112 mm and mounting depth is 81.5 mm. Flush-fit installations use a 120 mm cutout with CFB3-R or CFB3-SQ pre-construction kits; retrofit installations use a 90 mm cutout with the CFB3-KIT.
System expansion
CF230 can be used on its own or combined with the Monitor Audio ICS-8 architectural subwoofer for a concealed full-range system.
