Lumaris Downlights

Lutron Lumaris tunable white downlights for RadioRA 3 — 1800K–4000K with natural warm dim, 800 lumens, 90+ CRI, flicker-free dimming to 0.1%, and California Title 24 / JA8 listing. Controlled natively over Clear Connect – Type X, so no control wire is pulled. White or black trim on every model.

Specify by installation type and size class

  • Retrofit 4 in (RRL-RD4 series) — 3 in aperture, drops into existing 4 in cans.
  • Retrofit 6 in (RRL-RD6 series) — 4 in aperture, drops into existing 5 in/6 in cans.
  • Canless 4 in (RRL-CD4 series) — remodeler style for new ceiling openings.
  • Canless 6 in (RRL-CD6 series) — remodeler style for larger rooms and higher ceilings.

Retrofit and canless models, 4 in and 6 in classes, and RadioRA 3 (RRL-) versus HomeWorks QSX (HWL-) model numbers are not interchangeable. Power each fixture from constant 120 V — never through a phase-control dimmer. Browse the full Lumaris catalog.
