Lotus 2" 24V Eyeball Round Recessed Gimbal LED 5W | LL2G24V
Lotus 2" 24V Eyeball Round Recessed Gimbal LED 5W | LL2G24V
Available to order — ships from incoming stock
Typically ships in 1–3 Business Days (Western Canada) · 2–4 Business Days (Eastern Canada)
SKU:LL2G24V-30K-WH
MPN: LL2G24V-30K-WH
Shipping terms (Free over $300) calculated at checkout.
Overview
The Lotus LED 2" 24V Eyeball Round Recessed Gimbal is a low-voltage, architectural-spec lighting solution designed for precision illumination in restricted spaces. This 5W fixture features a unique, patented gimbal design that maintains an air-tight seal without the need for a traditional housing. It is specifically engineered for cabinets, recessed alcoves, sloped ceilings, and highlighting artwork.
Key Features
- Low Profile Design: Only 1 1/2" deep, making it ideal for installations where ceiling space is severely limited.
- Adjustable Directional Beam: Features a 20° tilt and 360° rotation for precise light placement on featured surfaces or artwork.
- IC Rated & Air-Tight: Certified for direct contact with insulation and air-tight installation, simplifying setup in residential and commercial projects.
- Contractor-Grade Construction: Includes a DC module for regulating voltage and current, ensuring long-term performance and reliability.
- Wet Location Rated: IP 54 certified and approved for use in insulated ceilings and wet locations.
Technical Specifications
- Energy Used: 5W
- Light Output: 380 | 400 | 430 lumens
- Halogen Equivalent: 35W
- Color Temperature: 2700K, 3000K, 4100K
- Beam Angle: 24° beam with 20° tilt and 360° rotation
- CRI: 90+
- Input: 24V DC
- Dimming: Not Dimmable
- Aperture/Dimensions: ID 2", OD 2 1/2"
- Cut-Out: 2" to 2 1/2"
- Ceiling Clearance: 1 1/2"
- IP Rating: IP 54
- Air Tight: Yes
- Operating Temperature: -40°F (-40°C) to +104°F (+40°C)
- Projected Life: 70% light output at 50,000 hours
- Certification: cULus, Type IC
- Warranty: 3 year when installed with a Lotus LED Lights Driver
