Lotus 5 LED Rotatable Linear Recessed Downlight 16W | JXL-TXH05-G16W
Lotus 5 LED Rotatable Linear Recessed Downlight 16W | JXL-TXH05-G16W
Available to order — ships from incoming stock
Typically ships in 1–3 Business Days (Western Canada) · 2–4 Business Days (Eastern Canada)
SKU:JXL-TXH10-T18W-5CCT-BK-45°
Shipping terms (Free over $300) calculated at checkout.
Overview
The Lotus LED 10 LED Linear Recessed fixture is an architectural-spec solution designed for unique and original lighting installations in residential, commercial, and hospitality settings. This linear luminaire features an integrated driver within a connection box, making it a streamlined choice for modern interior designs.
Key Features
- 5CCT User Selectable: Field-adjustable color temperatures allow for easy customization between 2700K and 5000K.
- IC Rated: Contractor-grade construction approved for direct contact with insulation, requiring no bulky recessed housing.
- Slim 2" Profile: Engineered for versatility, this fixture can be installed in tight plenums where ceiling space is limited.
- Dimmable: Includes a 120V TRIAC dimmable driver, allowing for smooth light control from 100% down to 20%.
- Architectural Versatility: Available in both 30° and 45° beam angles with white or black trim options to suit various design requirements.
Technical Specifications
- Power: 18W
- Light Output (White Reflector): 930 lm – 1230 lm
- Color Temperature: 5CCT Selectable (2700K, 3000K, 3500K, 4000K, 5000K)
- CRI: 80
- Beam Angle: 45° (default) or 30°
- Input Voltage: 120V AC 50/60 Hz
- Dimensions: 11 5/8" x 2 5/16" (Outside); 2" Depth
- Cut Out: 10 5/8" x 1 1/2"
- Approved Location: Insulated Ceiling & Damp Locations
- Air Tight: Yes
- Ambient Temperature: -4°F (-20°C) to +104°F (+40°C)
- Projected Life: 70% light output at 30,000 hours
- Certifications: cETLus
- Warranty: 3 Year
