Lotus 24V 288W 5-in-1 Dimmable cULus Driver with Built-in Wiring Chambers 120-277V Wet | SMT-024-288VTD52JV2

• Input: 120V – 277V AC
• Output: 24 V DC / 3 x 4 A
• maximum Load: 288 W
• 5-in-1 forward and reverse phase dimming: TRIAC / ELV / MLV, 0-10V, 1-10V, Potentiometer, 10V PWM
• Approved Locations – Dry, Damp & Wet
• Wiring Volume – 11 cu in per chamber
• Ambient Temperature: -40°F (-40°C) to +140°F (+60°C)
• Compliance: cULus Listed file # E507826
• Warranty: 7 Year

DIMENSIONS:

• Length 12″; Width 4 1/4″; Depth 1 3/4″

Product Features

• 288 W maximum load (3 x 96W multi)
• 120V-277 V AC Input
• 24 V DC Output / 3 x 4 A
• 5-in-1 forward and reverse phase dimming: TRIAC / ELV / MLV, 0-10V, 1-10V, Potentiometer, 10V PWM
• Wiring Compartments for Line and Low Voltage Connections
• Wet Location
• cULus Listed
• Warranty: 7 Year
