7" Round Surface Mount Edgelit Disk 3000K | ADS7R9
7" Round Surface Mount Edgelit Disk 3000K | ADS7R9
Available to order — ships from incoming stock
Typically ships in 1–3 Business Days (Western Canada) · 2–4 Business Days (Eastern Canada)
SKU:ADS7R9-5CCT-D-WH
ADS7R9-3K-WH | 7" Round Surface Mount Edgelit Disk 3000K
The Lotus ADS7R9-3K-WH is a 7-inch round surface mount edgelit LED disk designed for residential, commercial, hospitality, and multi-family lighting applications. Its lower-profile design and narrow flange create a clean architectural appearance for spaces where recessed lighting is not practical or where a slim surface-mounted fixture is preferred.
This 15W 3000K surface mount disk delivers 1240 lumens with CRI 90+ color rendering, a wide 100° beam angle, and 120V AC Triac dimming from 10% to 100%. Wet-location approval, flicker-free AC design, included mounting hardware, and J-box or retrofit installation flexibility make it a strong general-purpose disk light for residential and light commercial projects.
Why this fixture sells
- Low-profile edgelit design: slim 7" surface mount fixture with narrow flange
- Warm 3000K output: popular residential and hospitality color temperature
- Strong output: 1240 lumens from only 15W
- High color accuracy: CRI 90+ for true color rendering
- Wide beam spread: 100° beam angle for broad general illumination
- Fast installation: installs in a J-box or as a retrofit with optional retrofit kit
- Wet location approved: suitable for indoor and outdoor installations where permitted by code
- Triac dimmable: 120V AC dimming from 10% to 100%
- Mounting hardware included: supports faster jobsite installation
- Emergency backup accessory compatible: compatible with listed emergency battery accessory for single CCT models
Recommended applications
- Residential ceiling lighting
- Commercial general lighting
- Hospitality spaces
- Multi-family corridors and suites
- Bathrooms and wet-location areas
- J-box surface mount installations
- Retrofit projects where recessed lighting is not practical
Key specifications
| Model | ADS7R9-3K-WH |
|---|---|
| Fixture Type | 7" Surface Mount Edgelit Disk |
| Applications | Residential, Commercial, Hospitality, Multi Family |
| Power | 15 W |
| Color Temperature | 3000K |
| Light Output | 1240 lm |
| Halogen Equivalent | 120 W |
| Beam Angle | 100° |
| CRI | 90+ |
| Voltage Input | 120V AC |
| Dimming | Triac dimmers, 10% - 100% |
| Approved Location | Wet Locations |
| Air Tight | No |
| Ambient Temperature | -4°F (-20°C) to +104°F (+40°C) |
| Projected Life | 70% light output at 50,000 hours |
| Dimensions | 7 7/8" OD x 5/8" thickness |
| Certification | cETLus |
| Warranty | 5 Year |
Available model
- ADS7R9-3K-WH: 3000K, White trim
Compatible accessories
- Retrofit kit for ADS7R9: ordered separately
- EMB-SF001: Emergency battery backup, compatible with single CCT models only
- EMBS: Empty surface mount backbox for EMB-SF001
Installation notes
- Designed for fast installation in a J-box or as a retrofit.
- Mounting hardware is included.
- Retrofit kit is ordered separately.
- Emergency battery backup accessories are compatible with single CCT models only.
- Wet-location approved when installed according to code and manufacturer instructions.
- 7" round surface mount edgelit disk
- 15W power consumption with 120W halogen equivalent
- 3000K warm white output
- 1240 lumens with CRI 90+
- 100° beam angle
- 120V AC Triac dimmable, 10%-100%
- Wet location approved
- J-box or retrofit installation
- White trim
Frequently Asked Questions
What is the Lotus ADS7R9-3K-WH?
It is a 7-inch round surface mount edgelit LED disk fixture with 3000K warm white output and white trim.
Is this fixture color selectable?
No. This version is a fixed 3000K single-CCT model. For selectable color temperature, use the ADS7R9 5CCT version.
Is the ADS7R9-3K-WH dimmable?
Yes. It is designed for 120V AC Triac dimming from 10% to 100%.
Can this fixture be used in wet locations?
Yes. The ADS7R9 is wet-location approved when installed according to code and manufacturer instructions.
Can it be installed as a retrofit?
Yes. The fixture can be installed in a J-box or as a retrofit using the ADS7R9 retrofit kit, ordered separately.
Is emergency battery backup available?
Yes. The spec sheet lists emergency battery backup accessory EMB-SF001 as compatible with single CCT models only.
ADS7R9-4K-WH | 7" Round Surface Mount Edgelit Disk 4000K
The Lotus ADS7R9-4K-WH is a 7-inch round surface mount edgelit LED disk designed for residential, commercial, hospitality, and multi-family lighting applications. Its low-profile form and narrow flange provide a clean, elegant appearance for general ceiling lighting where recessed fixtures are not required.
This 15W 4000K surface mount disk delivers 1300 lumens with CRI 90+ color rendering, a wide 100° beam angle, and 120V AC Triac dimming from 10% to 100%. The neutral 4000K output makes it a strong option for commercial, utility, corridor, and multi-family spaces where crisp general illumination is preferred.
Why this fixture sells
- Low-profile edgelit design: slim 7" disk with narrow flange
- Neutral 4000K output: crisp light for commercial, utility, and multi-family applications
- High output: 1300 lumens from only 15W
- High color accuracy: CRI 90+ for true color rendering
- Wide beam spread: 100° beam angle for broad general illumination
- Fast installation: installs in a J-box or as a retrofit with optional retrofit kit
- Wet location approved: suitable for indoor and outdoor installations where permitted by code
- Triac dimmable: 120V AC dimming from 10% to 100%
- Mounting hardware included: supports clean jobsite installation
- Emergency backup accessory compatible: compatible with listed emergency battery accessory for single CCT models
Recommended applications
- Commercial general lighting
- Residential ceiling lighting
- Hospitality spaces
- Multi-family corridors and suites
- Utility rooms and common areas
- Bathrooms and wet-location areas
- J-box surface mount installations
- Retrofit projects
Key specifications
| Model | ADS7R9-4K-WH |
|---|---|
| Fixture Type | 7" Surface Mount Edgelit Disk |
| Applications | Residential, Commercial, Hospitality, Multi Family |
| Power | 15 W |
| Color Temperature | 4000K |
| Light Output | 1300 lm |
| Halogen Equivalent | 120 W |
| Beam Angle | 100° |
| CRI | 90+ |
| Voltage Input | 120V AC |
| Dimming | Triac dimmers, 10% - 100% |
| Approved Location | Wet Locations |
| Air Tight | No |
| Ambient Temperature | -4°F (-20°C) to +104°F (+40°C) |
| Projected Life | 70% light output at 50,000 hours |
| Dimensions | 7 7/8" OD x 5/8" thickness |
| Certification | cETLus |
| Warranty | 5 Year |
Available model
- ADS7R9-4K-WH: 4000K, White trim
Compatible accessories
- Retrofit kit for ADS7R9: ordered separately
- EMB-SF001: Emergency battery backup, compatible with single CCT models only
- EMBS: Empty surface mount backbox for EMB-SF001
Installation notes
- Designed for fast installation in a J-box or as a retrofit.
- Mounting hardware is included.
- Retrofit kit is ordered separately.
- Emergency battery backup accessories are compatible with single CCT models only.
- Wet-location approved when installed according to code and manufacturer instructions.
- 7" round surface mount edgelit disk
- 15W power consumption with 120W halogen equivalent
- 4000K neutral white output
- 1300 lumens with CRI 90+
- 100° beam angle
- 120V AC Triac dimmable, 10%-100%
- Wet location approved
- J-box or retrofit installation
- White trim
Frequently Asked Questions
What is the Lotus ADS7R9-4K-WH?
It is a 7-inch round surface mount edgelit LED disk fixture with 4000K neutral white output and white trim.
Is this fixture color selectable?
No. This version is a fixed 4000K single-CCT model. For selectable color temperature, use the ADS7R9 5CCT version.
Is the ADS7R9-4K-WH dimmable?
Yes. It is designed for 120V AC Triac dimming from 10% to 100%.
Can this fixture be used in wet locations?
Yes. The ADS7R9 is wet-location approved when installed according to code and manufacturer instructions.
Can it be installed as a retrofit?
Yes. The fixture can be installed in a J-box or as a retrofit using the ADS7R9 retrofit kit, ordered separately.
Is emergency battery backup available?
Yes. The spec sheet lists emergency battery backup accessory EMB-SF001 as compatible with single CCT models only.
